Smart IOT for the sharing e-bikes — WD-210
(1)Functions of central control IoT
TBIT independent research and development of many 4G intelligent control, can be applied to shared two-wheelers business, the main functions include real-time positioning, vibration detection, anti-theft alarm, high precision positioning, fixed-point parking, civilized cycling, manned detection, intelligent helmet, voice broadcast, headlight control, OTA upgrade, etc.
(2)Application scenarios
① Urban transportation
② Campus green travel
③ Tourist attractions
(3)Advantages
The shared central control IoT devices of TBIT offer numerous advantages that meet the needs of shared mobility businesses. Firstly, They provide a more intelligent and convenient cycling experience for users. It easy for users to rent, unlock, and return the vehicle, saving them time and effort. Secondly, the devices help businesses achieve refined operations. With real-time data collection and analysis, businesses can optimize their fleet management, improve service quality, and enhance user satisfaction.
(4)Quality
We have our own factory in China, where we strictly monitor and test the product quality during production to ensure the best quality possible. Our commitment to excellence extends from the selection of raw materials to the final assembly of the device. We use only the finest components and adhere to strict quality control procedures to guarantee the stability and durability of our shared central control IOT device.
Sharing IOT devices of TBIT combined with GPS + Beidou, make the positioning more accurate, with Bluetooth spike, RFID, AI camera and other products can realize fixed point parking, solve the problem of urban governance.Product support customization, the price discount, is the ideal choice for shared bike / shared electric bike / shared scooter operators!
Our smart shared IOT device will provide a more intelligent / convenient / safer cycling experience for your users，meet your shared mobility business needs, and help you to achieve refined operations.
Acceptance: Retail,Wholesale,Regional Agency
Product quality：We have our own factory in China. In order to ensure the stability of product performance, our company strictly monitors and tests the product quality in production to ensure the good quality of products.We will be your most trusted shared IOT device provider!
About sharing scooter iot,any inquiries we are happy to reply, pls send your questions and orders.
Functions of WD-210:
| Positioning | Arm Alarm | Disarm Alarm |
|---|---|---|
| 485 Communication (Compatible with CAN/Serial Port) | Real-time Data Upload | OTA Upgrade |
| Vibration Detection | Wheel Movement Detection | ACC Detection |
| Tip-over Alarm | Motor Lock | Device Sleep Mode |
| Voice Function | Battery Lock Control | BMS Data Reading |
| Helmet Lock Control | RFID (Optional) | AI Camera (Optional) |
Specifications:
| Parameter Item | Specification |
|---|---|
| Overall Dimensions | L×W×H: 109.82mm × 73.20mm × 31.50mm |
| Input Voltage Range | Wide voltage input: 12V-72V |
| Power Consumption | Normal operation：<15mA@48VSleep standby：<4mA@48V |
| Dustproof & Waterproof Grade | IP67 |
| Housing Material | V0 flame-retardant PC |
| Housing Weight | 67g±1g |
| Operating Temperature | -30 ℃ ～ +70 ℃ |
| Operating Humidity | 5%RH ～ 95%RH |
| SIM Card Type | Micro-SIM card / Patch SIM card |
Network Performance：
| Parameter Item | Specification |
|---|---|
| Supported Modes | LTE-FDD/LTE-TDD |
| Max Transmit Power | LTE-FDD/LTE-TDD：23dBm |
| Frequency Bands | LTE-FDD: B1/B3/B5/B8LTE-TDD: B34/B38/B39/B40/B41 |
Satellite Positioning Performance：
| Parameter Item | Specification |
|---|---|
| Satellite Receiving Bands | China BDS: B1I,B1C,B2a,B2I,B2b,B3IUS GPS / Japan QZSS: L1 C/A,L1C,L2C,L5Russia GLONASS: L1,L2EU Galileo: E1,E5a,E5b |
| Startup Time | Cold start ≤28S |
| Positioning Accuracy | 3-5 meters（open area） |
| Sensitivity | Cold start：-148dBmRe-capture：-158dBmTracking：-167dBm |
| AGPS | Supported |
Bluetooth Performance：
| Parameter Item | Specification |
|---|---|
| Bluetooth Version | BLE5.4 |
| Receiving Sensitivity | -93dBm |
| Max Receiving Distance | 30 meters (open area) |
| On-vehicle Receiving Distance | 10-20 meters (depends on installation environment) |
Product features：
(1) Multiple positioning methods
It supports the flexible combination of single-frequency single-point, dual-frequency single-point, and dual-frequency RTK, and the accuracy can reach up to sub-meter positioning accuracy.
(2) Support the inertial navigation algorithm
It supports inertial navigation algorithms to enhance the localization ability of weak signal areas and reduce GPS drift problems.
(3) Ultra low power consumption
The self-developed ultra-low power consumption algorithm greatly reduces the power consumption, and the standby time is doubled compared with the company's previous generation products.
(4) Double road 485 communication
It supports dual-channel 485 communication, and the peripheral accessories are more expandable, and can support functions such as high-traffic data backhaul such as AI camera pictures without affecting the data interaction of batteries and controllers.
(5) Support industrial-grade patch
Support industrial-grade SMD SIM card, high and low temperature, strong vibration, and stronger anti-interference ability.
